4x10 Combo Specifications
  • Hand Wired All Tube Combo Amplifier
  • 50 Watts Output
  • Two Channels (Normal & Bright)
  • Hi & Low Level Inputs (each per channel)
  • Two Volume Controls (individual per channel)
  • EQ Controls: Bass, Mid, Treble, Presence
  • Tube Compliment:
    • 3-12AX7 Preamp Tubes
    • 1-GZ34 Rectifier
    • 2-Matched 6L6GC Output Tubes
  • Four Jensen P10R 25w Ten Inch Alnico Speakers
  • Speaker Impedance: 8ohms
  • System Impedance: 2ohms
  • Open Back Cabinet Design
  • On/Off Toggle Switch
  • Jeweled Illuminated Power Indicator
  • Standby Toggle Switch
  • Ground Lift / Polarity Toggle Switch
  • Fuse Protection
  • Grounded Plug
  • Reinforced Stitched Leather Strap Handle
  • Tolex Covering (Purple)
  • Finger Jointed Pine Cabinet Construction
  • Optional Fitted Cover Available
  • Weight: 47 lbs.
  • Dimensions: 23.5" H x 22-5/8" W x 10.5" D
